- stroke 5mm
- thrust 110N ( NC version ) 200N ( NA version )
- linear motion
- 2W consumption
- ferrule connection M30x1,5mm
- protection degree IP54
- casing material: self-extinguishing V0
- auxiliary contact : Max 700 mA - 250 V ~ (a. c.)
- Double insulation construction
- mechanical position indicator
- model utility-Patent inherent the union between base and cover.
Special electrothermic actuator
Electrothermic actuators compact on/off action electrothermic actuator compatible with thermostatable radiator valves, fan-coil valves and manifolds.
Available variants:
- CABLE LENGTH 2 MT
- CABLE LENGTH 3 MT
- CABLE LENGTH 0.60 MT WITH INSULATED FASTON
- CABLE LENGTH 1 MT WITH INSULATED FASTON
- VOLTAGE 110V
Main features:
Technical data:
| Code | Description | Protection | Packaging |
| TECH2230-5 | electrothermal actuator NC 2 wires 230V | ip54 | 50 |
| TECHAUX230-5 | electrothermal actuator NC 4 wires 230V | ip54 | 50 |
| TECH224-5 | electrothermal actuator NC 2 wires 24V | ip54 | 50 |
| TECHAUX24-5 | electrothermal actuator NA 2 wires 230V | ip54 | 50 |
| TEAPAUX230-5 | electrothermal actuator NA 4 wires 230V | ip54 | 50 |
| TEAP224-5 | electrothermal actuator NA 2 wires 24V | ip54 | 50 |
| TEAPAUX24-5 | electrothermal actuator NA 4 wires 24V | ip54 | 50 |
